The LiveGuard Dashboard

The same unified dashboard, extended with a LIVEGUARD section — 5 real-time tabs driven by WebSocket hub events.

Opening the Dashboard

The LiveGuard section is part of the unified Plan Forge dashboard — no separate app or port required:

node pforge-mcp/server.mjs

Open localhost:3100/dashboard. The LIVEGUARD section appears in the tab bar after a visual divider, separated from the FORGE section.

Two Sections, One Dashboard

The tab bar uses a two-section layout:

FORGE tabs use a blue active indicator. LIVEGUARD tabs use amber — you always know which half of the dashboard you're in.

Health Tab

The Health tab shows aggregate project health powered by forge_health_trend. Key widgets:

• Health Score — a single 0–100 number, color-coded: green (80+), amber (50–79), red (<50). Computed from drift, incidents, cost, and model performance.
• Drift Trend — 30-day line chart of architecture drift scores. The x-axis is time; the y-axis is score 0–100.
• MTTBF — Mean Time Between Failures, calculated from incident timestamps. Lower is worse.
• Cost Trend — monthly aggregated cost from forge_cost_report.

The Health tab auto-refreshes on every liveguard-tool-completed WebSocket event. No manual refresh needed.

Incidents Tab

Live list of open incidents from .forge/incidents/. Each card shows:

• Incident ID — unique identifier
• Severity badge — color-coded: red (critical), orange (high), yellow (medium), grey (low)
• MTTR — time elapsed since the incident was captured, updated in real-time
• On-call — engineer name from .forge.json onCall config
• Affected files — file list, clickable to view in editor

Fix Proposals Feed (v2.29) — when forge_fix_proposal has generated plans, a Proposed Fixes section appears at the top of the Incidents tab. Each entry shows the proposal file path, source type (regression/drift/incident/secret), and a Run in Assisted Mode → button that opens the Actions tab pre-filled with the plan path. The feed reads from GET /api/fix/proposals on tab load and on every fix-proposal-ready hub event.

Triage Tab

Displays the output of forge_alert_triage — a ranked list of all open alerts sorted by priority (severity × recency). Each row shows:

• Source — which tool generated the alert (drift, regression, dep-watch, etc.)
• Severity — badge matching the severity matrix in Appendix F
• Priority score — computed rank (higher = address first)
• Description — one-line summary
• Timestamp — when the alert was generated

Critical and high alerts show a red/amber left-border on their row. The tab badge shows the total number of unresolved critical+high alerts.

Security Tab

Surfaces results from forge_secret_scan. Shows:

• Scan status — clean (green shield) or findings (red shield with count)
• Findings list — file path, line number, type (api_key, token, etc.), entropy score, confidence level. Values are never shown — only <REDACTED> placeholders.
• Last scan time — from cache file
• Run Scan button — triggers POST /api/secrets/scan

The Security tab reads from .forge/secret-scan-cache.json on load and refreshes on liveguard-tool-completed events where tool === "forge_secret_scan".

Env Tab

Key-by-key comparison of all .env.* files in the project root, powered by forge_env_diff.

• Key matrix — rows are env keys, columns are files. Present keys show a green check; missing keys show a red ✗.
• Gap count — total missing keys, highlighted in the tab badge
• Values are never displayed — the Env tab shows key names only
• Run Diff button — triggers POST /api/env/diff

The tab reads from .forge/env-diff-cache.json on load. Cache is refreshed when forge_env_diff completes.

Quorum Analysis from the Dashboard (v2.29)

The Health and Incidents tabs each include a Run Quorum Analysis → link. Clicking it calls GET /api/quorum/prompt?source=<tab-source>&goal=risk-assess and opens a pre-populated quorum prompt in the Actions tab, ready to copy into your AI client. No model calls happen from the dashboard — it assembles the prompt for you.

Help Links from the Dashboard

Each LiveGuard tab header includes a Docs ↗ link. Clicking it opens this chapter in a new tab — you never lose your live dashboard session. The section header also has a Docs link pointing to this page's overview.
