Integrating from Outside

MCP is the native transport for Copilot and similar agents, but it is not the only one. Plan Forge ships four orthogonal surfaces so any tool can drive the workshop: REST for HTTP-anything, SDK for Node.js callers, WebSocket hub for live event streams, and CLI for scripts and humans.

The four surfaces, at a glance

The same handler set lives behind all four surfaces. Adding a new tool means the team writes one handler, and it automatically becomes available as MCP tool, REST endpoint, CLI command, and SDK export. This is intentional: the integration surface should never be the bottleneck for a new capability.

REST API

The REST surface is the right choice for any caller that already speaks HTTP, GitHub Actions, GitLab CI, a Python script, a curl one-liner, a Postman collection. It is also the surface the dashboard itself uses.

Base URL and auth

# Local dev (default)
http://localhost:3100/api

# Auth: bearer token from .forge/secrets.json (key: "apiToken")
curl -H "Authorization: Bearer $PFORGE_API_TOKEN" \
     http://localhost:3100/api/plan/status

Tokens are generated by pforge auth issue and stored locally in .forge/secrets.json (gitignored). Multi-developer setups use one token per developer; CI uses a dedicated CI token with scoped permissions.

The 17+ domains

The 113 endpoints organize into 16 subsystems that mirror the MCP tool families. The full per-endpoint reference lives in Appendix W — REST API Reference; this chapter covers the shape:

Every endpoint returns RFC 7807 ProblemDetails on error and a structured JSON object on success. The OpenAPI spec lives at GET /api/openapi.json if you need codegen.

WebSocket hub — /api/hub

The WebSocket hub is a broadcast channel that emits every event the orchestrator generates, plan starts, slice transitions, gate results, cost samples, bug filings, drift updates. It is the substrate the dashboard's live tiles render off.

Connecting

// Node.js
import { WebSocket } from "ws";
const ws = new WebSocket("ws://localhost:3100/api/hub", {
  headers: { Authorization: `Bearer ${process.env.PFORGE_API_TOKEN}` }
});

ws.on("message", (raw) => {
  const event = JSON.parse(raw.toString());
  console.log(event.type, event.payload);
});

Event shape

{
  "type":    "slice.commit",       // canonical event name
  "ts":      "2026-05-17T09:18:41Z",
  "actor":   "alice@example.com",
  "plan":    "Phase-31",
  "slice":   "2",
  "payload": { sha: "e4f5g6h", durationMs: 24100, gates: ["pass","pass"] }
}

The full event catalog, 38 event types across eight families with envelope, source/security_risk enums, payloads, and retention, lives in Appendix V — Event Catalog. The canonical JSON schema lives in pforge-mcp/EVENTS.md. Subscribe to all events or filter by type:

ws.send(JSON.stringify({
  subscribe: ["slice.*", "gate.fail", "bug.opened"]
}));

pforge-sdk — the Node.js client

For TypeScript / JavaScript callers, pforge-sdk is a thin wrapper over the REST and WebSocket surfaces with typed responses and bundled helpers. It ships with four entry points:

Worked example

import { createClient } from "pforge-sdk";
import { forgeRunPlan, forgeEstimateQuorum } from "pforge-sdk/tools";

const client = createClient({
  baseUrl: "http://localhost:3100",
  token:   process.env.PFORGE_API_TOKEN
});

// Estimate before running (cost discipline, never hand-compute)
const est = await forgeEstimateQuorum(client, { plan: "docs/plans/Phase-31-PLAN.md" });
console.log("Cheapest mode:", est.recommendation);

// Execute
const run = await forgeRunPlan(client, {
  plan:   "docs/plans/Phase-31-PLAN.md",
  quorum: est.recommendation
});

// Subscribe to live events for this run
const sub = client.subscribe(["slice.*", "gate.*", "plan.complete"]);
for await (const event of sub) {
  if (event.plan !== "Phase-31") continue;
  console.log(event.type, event.payload);
  if (event.type === "plan.complete") break;
}

CLI — for scripts and humans

The CLI is the right surface for ad-hoc scripts, cron jobs, and direct human use. Every command has a --json flag for machine-readable output, so it composes cleanly with shell pipelines and CI scripts.

# Run a plan and pipe the result into jq
pforge run-plan docs/plans/Phase-31-PLAN.md --json | jq '.cost.totalUsd'

# Loop until a plan completes (useful in CI)
while [ "$(pforge plan-status --json | jq -r '.state')" != "complete" ]; do
  sleep 30
done

# Daily digest into Slack
pforge digest --post

# Cost rollup for the month
pforge cost-report --since=30d --json | jq '.byModel'

The full 97-command reference lives in Chapter 8 — CLI Reference. The pforge --help output is the canonical source.

Picking the right surface

Auth and secrets

All four surfaces share the same auth model:

• Bearer tokens in the Authorization header (REST + WebSocket) or as PFORGE_API_TOKEN env var (CLI + SDK).
• Tokens are issued via pforge auth issue [--scope=…] and stored in .forge/secrets.json (gitignored).
• The MCP surface authenticates via the transport itself, stdio inherits the parent process trust; WebSocket MCP uses the same bearer token model.
• Outbound API keys (Anthropic, OpenAI, xAI, Azure) live in .forge/secrets.json under providers.* or in environment variables. Never in code, never in committed config.
