REST API Reference

Every REST endpoint the Plan Forge MCP server exposes, grouped by subsystem, with verb, path, request body shape, response shape, and status codes. The companion to Appendix V — Event Catalog (which covers the WebSocket side) and Appendix Q — API Surface Index (which catalogs the MCP tool surface).

Orientation

Plan Forge exposes ~91 REST endpoints across 16 subsystems. Every one of the 106 MCP tools can also be invoked over REST through the generic dispatcher (POST /api/tool/:name), the explicit endpoints below are the "first-class" surfaces the dashboard and CLI use, with response shapes shaped for direct UI consumption rather than tool-call envelopes.

Authentication, binding, and CORS

The trust model is local user. The server binds explicitly to 127.0.0.1 (loopback only) and runs no authentication layer of its own, the operating system's user account is the access boundary. Concretely:

• Binding: app.listen(HTTP_PORT, "127.0.0.1", ...), remote hosts cannot reach the API; only processes running as the same OS user can.
• Port: 3100 by default; override with PLAN_FORGE_HTTP_PORT (see Appendix U — Server Ports).
• CORS: not enabled. Browser dashboards served from http://127.0.0.1:3100/dashboard share the same origin.
• Bridge approvals (the only endpoint family that crosses a trust boundary) are protected by the per-run HMAC token in PFORGE_BRIDGE_SECRET, see Bridge & approvals.

If you need to expose the API beyond loopback (rare; usually it's the wrong solution), put a reverse proxy in front of it that handles TLS and authentication. Do not change the bind address; it's a deliberate safety boundary.

Error response shape

Endpoint handlers wrap exceptions in a consistent envelope:

// 4xx / 5xx
{
  "error": "Human-readable message",
  "code": "OPTIONAL_MACHINE_CODE",   // e.g. ASK_QUESTION_MISMATCH, PLAN_ALREADY_EXISTS
  "details": { ... }                  // optional structured context
}

Status codes follow standard HTTP semantics: 400 for malformed input, 404 for missing resources, 409 for state conflicts (most common in Crucible finalize), 413 for body limits, 500 for unexpected server errors. The complete error-code table lives in the Errors & Exit Codes appendix (forthcoming Appendix X).

Discovery

Lightweight endpoints intended for liveness checks, build identification, and capability negotiation. These are safe to poll, none of them allocate workers or write files.

Method	Path	Purpose	Response
GET	/.well-known/plan-forge.json	Public discovery manifest	{ version, capabilities, dashboard }
GET	/api/capabilities	Full capability catalog (mirrors forge_capabilities)	{ tools[], workflows[], config, memory }
GET	/api/version	Running server version	{ version, framework, build }
GET	/api/status	Liveness + last error	{ ok, lastError, uptimeMs }

Plan execution and runs

The lifecycle surface for pforge run-plan. Triggering a run returns immediately with a run ID; subscribe to the lifecycle event family over the WebSocket hub for progress.

Method	Path	Purpose	Request / response notes
GET	/api/runs	List recent runs (last 50)	Returns { runs: [{ id, plan, status, startedAt, endedAt }] }.
GET	/api/runs/latest	Latest run with full status	Includes current slice, gate result, cost so far.
GET	/api/runs/:runIdx	Specific run by index	runIdx matches .forge/runs/<idx>.jsonl.
POST	/api/runs/trigger	Kick off a plan run	Body: { plan, mode, quorum, assisted, dryRun, escalate }. Returns { runIdx, pid }.
POST	/api/runs/abort	Abort the active run	Body: { runIdx? } (defaults to current). Sends SIGTERM, then SIGKILL after grace.
GET	/api/replay/:runIdx/:sliceId	Session replay log for a slice	Returns the journaled stdout/stderr stream for one slice, used by the dashboard's session-replay view.
GET	/api/plans	Enumerate hardened plans	Walks docs/plans/ and parses Scope Contract headers.
GET	/api/workers	Active worker processes	PIDs, model, slice, elapsed.
GET	/api/traces	List execution traces (run index)	Top-level summary: run, slice count, gate pass/fail.
GET	/api/traces/:runId	Trace detail for one run	Per-slice timing, model, tokens in/out, cost.

Cost

Plan Forge tracks token spend per provider, per model, per run, aggregated monthly. The single REST endpoint mirrors forge_cost_report; richer estimation lives in MCP tools (see Generic MCP dispatcher).

Method	Path	Purpose	Response
GET	/api/cost	Cost report (token spend per model + monthly aggregation)	{ thisMonth, lastMonth, perModel: {...}, perRun: [...] }

Estimation endpoints (forge_estimate_quorum, forge_estimate_slice) are MCP-only; invoke via POST /api/tool/<name>.

Search, timeline, hub

Cross-surface search and the unified timeline are the dashboard's primary navigation aids. The hub endpoint is where browsers (and any other client) upgrade to a WebSocket to receive live events, see Appendix V — Consuming the Stream for a Node example.

Method	Path	Purpose	Notes
GET	/api/search	Cross-surface search (plans, events, bugs, incidents, memory)	Query string: ?query=&source=&limit=. Returns { hits: [{ source, recordRef, snippet, score, timestamp }], total, truncated, message }, the gold-standard ACI shape.
GET	/api/timeline	Unified event timeline	Cursor-paged: ?cursor=&limit=. Merges nine sources (runs, slices, deploys, incidents, drift, memory, bugs, crucible, tempering).
GET	/api/hub	WebSocket upgrade for live events	HTTP GET returns hub status + client count; same path accepts Upgrade: websocket for streaming.

Memory (L1 / L2 / L3)

The capture-and-recall surface that backs OpenBrain integration and the auto-skills system. See Chapter 22 — How the Shop Remembers for the architectural overview.

Method	Path	Purpose	Notes
GET	/api/memory	Memory landing, recent captures + state	Dashboard primary view.
GET	/api/memory/report	Aggregate stats	Captures/day, hit rate, top thoughts.
POST	/api/memory/search	Search L2 captures (and L3 if OpenBrain configured)	Body: { query, limit, source? }.
POST	/api/memory/capture	Capture a thought	Body: { content, tags, source }. Broadcasts memory-captured hub event.
POST	/api/memory/drain	Drain pending memory queue	Forces a flush of buffered captures to disk + L3.
GET	/api/memory/presets	Capture-rule presets	Predefined tag bundles (debugging, architecture, etc.).
GET	/api/brain/stats	OpenBrain integration stats	L3 connection state, capture count, embedding model.

Crucible (idea smelting)

The conversational planner surface. The full lifecycle is submit → ask → preview → finalize. See Chapter 5 — Crucible (Idea Smelting) for the workflow.

Method	Path	Purpose	Notes
POST	/api/crucible/submit	Start a new smelt	Body: { idea, source? }. Returns { smeltId, firstQuestion }.
POST	/api/crucible/ask	Answer current question, get next	Body: { smeltId, answer, questionId? }. Mismatched questionId returns 409 ASK_QUESTION_MISMATCH.
GET	/api/crucible/preview	Render current draft + unresolved fields	Query: ?smeltId=. Returns plan draft + criticalGaps[].
POST	/api/crucible/finalize	Atomically claim phase + write plan file	Returns 409 + criticalGaps[] if gaps remain; 409 + PLAN_ALREADY_EXISTS if file exists (pass overwrite: true).
POST	/api/crucible/abandon	Mark smelt abandoned	Frees the phase number for the next smelt.
GET	/api/crucible/list	List all smelts (filter by status)	Query: ?status=draft|finalized|abandoned.
GET	/api/crucible/config	Read Crucible config	Interview model, question budget, autopilot threshold.
POST	/api/crucible/config	Write Crucible config	Partial updates merged into .forge.json#crucible.
GET	/api/crucible/manual-imports	List manually-imported smelts	Spec Kit, hand-authored briefs.
GET	/api/crucible/governance	Governance summary	Autopilot rate, fallback rate, mean question count.

LiveGuard (drift, incidents, deploys)

The production-companion surface. Every endpoint here emits at least one event in the LiveGuard event family; subscribe over the hub to see real-time alerts.

Method	Path	Purpose	Notes
GET	/api/drift	Current drift score vs architecture rules	Returns { score, breakdown, asOf }. Score range 0–100.
GET	/api/drift/history	Drift trend over time	One entry per forge_drift_report invocation.
GET	/api/incidents	List incidents (severity, MTTR)	Sorted newest first; includes resolution timestamp + MTTR ms.
POST	/api/incident	Capture a new incident	Body: { title, severity, source, body }. Emits liveguard-incident.
GET	/api/deploy-journal	List deploys	Version, deployer, notes, linked run.
POST	/api/deploy-journal	Record a deploy	Body: { version, deployer, notes, runIdx? }.
POST	/api/regression-guard	Run regression gates against codebase	Body: { scope, baseline? }. Returns pass/fail per rule.
GET	/api/runbooks	List operational runbooks	One per alert class.
POST	/api/runbook	Generate or update a runbook	Body: { alertClass, content }.
GET	/api/health-trend	Health DNA aggregator	Drift + cost + incidents + test pass-rate over time.
GET	/api/hotspots	Git churn hotspots	Files with high change frequency, refactor candidates.
GET	/api/triage	Prioritized alert list	Drift + incidents + secrets + deps, ranked.
GET	/api/liveguard/traces	LiveGuard execution traces	One per forge_liveguard_run invocation.
GET	/api/secret-scan	Latest secret-scan results	Values redacted; returns { findings: [{ file, line, severity }] }.
POST	/api/secret-scan/run	Trigger a fresh scan	Body: { paths? }. Default scans full repo.
GET	/api/deps/watch	Latest dependency-vuln snapshot	Returns CVE list grouped by package.
POST	/api/deps/watch/run	Trigger a fresh dep scan	Body: { packageManager? }; auto-detects if omitted.
GET	/api/env/diff	Env-var key divergence across .env files	Catches the "key in dev but missing in prod" footgun.

Quorum and fix proposals

The bridge between LiveGuard findings and structured remediation. Quorum prompts gather context across drift/incident/deploy/secret findings; fix proposals materialize that context into an actionable plan slice.

Method	Path	Purpose	Notes
GET	/api/fix/proposals	List fix proposals	Sorted by recency; filter by ?status=.
POST	/api/fix/propose	Generate an actionable fix plan	Body: { findingId, model? }. Returns proposed plan-slice diff.
GET	/api/quorum/prompt	Read XSS-validated quorum prompt	Query: ?promptId=. Output is HTML-escaped for safe rendering.
POST	/api/quorum/prompt	Build a quorum prompt	Body: { findings: [...], mode }. Returns { promptId, url }.

Tempering and bugs

The bug-registry surface. Tempering scans for TODO/FIXME/stub markers and produces an artifact; the bug stub endpoint converts a finding into a registered bug. Bug create/update/validate is MCP-only; see Appendix Q.

Method	Path	Purpose	Notes
GET	/api/tempering/artifact	Latest tempering artifact	Scan results + temper score.
POST	/api/tempering/bug-stub	Create a bug stub from a finding	Body: { findingId, title? severity? }.
GET	/api/bugs/list	List registered bugs	Query: ?status=&severity=&plan=.

Skills (decision tray)

Auto-skills surface decisions that the orchestrator wants a human to make, tag the deferred work, accept/reject the proposal, or defer for later review.

Method	Path	Purpose	Notes
GET	/api/skills	Skill catalog	Includes hand-authored .github/skills/*/SKILL.md and auto-skills.
GET	/api/skills/pending	Pending decisions awaiting accept/reject	Query: ?source=.
POST	/api/skills/accept	Accept a pending decision	Body: { decisionId, note? }.
POST	/api/skills/reject	Reject a pending decision	Body: { decisionId, reason? }.
POST	/api/skills/defer	Defer a pending decision	Body: { decisionId, untilTimestamp? }.

Inner loop

The self-improvement surface. Inner-loop subsystems observe runs and propose tightenings: gate suggestions from observed failures, reviewer-score calibration, cost-anomaly detection, federation across sibling repos.

Method	Path	Purpose	Notes
GET	/api/innerloop/status	All inner-loop subsystem states	Returns rollup of the six subsystems below.
GET	/api/innerloop/reviewer-calibration	Reviewer-score calibration trace	Drift between auto-reviewer and human override decisions.
GET	/api/innerloop/gate-suggestions	Gate-tightening suggestions	Patterns where current gates allowed regressions.
GET	/api/innerloop/cost-anomalies	Cost anomalies across runs	Slices that cost >3σ above their plan baseline.
GET	/api/innerloop/proposed-fixes	Auto-proposed fixes from health-trend signals	Combines drift, incidents, and test trends.
GET	/api/innerloop/federation	Federation-mode status	Advisory cross-repo learning when configured.
POST	/api/innerloop/federation/toggle	Enable/disable federation	Body: { enabled }.

Bridge and approvals

The human-in-the-loop surface. When a plan slice is flagged for approval (assisted mode or escalation), the orchestrator emits an approval-requested event and waits. The browser-link variant is opened by VS Code notification; the POST variant is for programmatic clients.

Method	Path	Purpose	Notes
GET	/api/bridge/status	Pending approvals waiting for a human nudge	Returns { pending: [{ runId, sliceId, reason, createdAt }] }.
POST	/api/bridge/approve/:runId	Programmatic approval	Header X-Bridge-Token required (HMAC from PFORGE_BRIDGE_SECRET). Body: { decision: "approve"|"reject", note? }.
GET	/api/bridge/approve/:runId	Browser-link approval	Query ?token= with same HMAC; renders a confirm page. Used by VS Code notification & email links.

Copilot integration

The surface that powers the Copilot Integration Trilogy, reading, previewing, and syncing .github/copilot-instructions.md from the project profile + principles. OpenClaw endpoints post LiveGuard snapshots to the optional analytics service.

Method	Path	Purpose	Notes
GET	/api/copilot-instructions	Read current file	Returns raw markdown.
POST	/api/copilot-instructions/preview	Preview a regenerated file	Body: { projectProfile? principles? }. Non-destructive.
POST	/api/copilot-instructions/sync	Sync from project profile + principles	Writes the file; emits a hub event for editor refresh.
POST	/api/openclaw/snapshot	Post a LiveGuard snapshot to OpenClaw	Body: snapshot envelope. Requires openclaw.endpoint in .forge.json.
GET	/api/openclaw/config	OpenClaw endpoint + auth config	Token is masked in response.

GitHub and team coordination

Team-mode endpoints that wrap the gh CLI for read-only GitHub access plus a per-operator activity feed sourced from .forge/team-activity.jsonl.

Method	Path	Purpose	Notes
GET	/api/github-metrics	Live GitHub repo metrics	PRs open, stale branches, issue load. Requires gh auth login.
GET	/api/github-readiness	Readiness for Copilot Coding Agent dispatch	Validates labels, branch protection, repo settings.
GET	/api/team-dashboard	Per-operator stats + conflict risk	Aggregates team-activity.jsonl.
GET	/api/team-activity	Recent run summaries from team feed	Cursor-paged: ?cursor=&limit=.

Notifications, audit, dashboard, settings

The "everything else" administrative surface, notification channels, audit drain loop, dashboard state persistence, config + secrets read/write, extensions, update checks, soft restart.

Method	Path	Purpose	Notes
GET	/api/notifications/config	Notification channel config	Slack, Teams, PagerDuty, Email per .forge.json.
POST	/api/notifications/config	Update channels	Body: partial config; deep-merged.
GET	/api/audit/config	Audit drain loop config	Returns drain interval, ring sizes, destinations.
PUT	/api/audit/config	Update audit config	Full replacement of audit subtree.
POST	/api/audit/drain	Trigger one full drain pass	Useful before shutdown.
GET	/api/dashboard-state	Sticky dashboard tab + filter state	Per-user UI prefs.
POST	/api/dashboard-state	Persist dashboard state	Body: { tab, filters, layout }.
GET	/api/config	Read merged .forge.json	After env-var overlay and computed defaults.
POST	/api/config	Update config	Body: partial; deep-merged. Writes .forge.json.
GET	/api/secrets	Read .forge/secrets.json keys	Values masked; only key presence returned.
POST	/api/secrets	Update local secrets store	Body: { key, value }. Writes the gitignored file.
GET	/api/extensions	Installed extensions	From .forge/extensions/.
GET	/api/update-status	Update-check status	Latest release, currency, channel.
POST	/api/self-update	Trigger self-update install	Runs pforge self-update; restart required afterward.
POST	/api/server/restart	Soft-restart the MCP server	HMR-friendly: re-loads code without dropping the WebSocket clients (best-effort).

Generic MCP dispatcher

The escape hatch. Any of the 106 MCP tools can be invoked over REST through this surface, useful for SDK clients, CI scripts, and any external integration that needs richer tool semantics than the first-class endpoints expose.

Method	Path	Purpose	Notes
POST	/api/tool/:name	Invoke any of the 106 MCP tools over REST	Body is the tool's input contract (see Appendix Q). Response is the tool's output payload, unwrapped from the MCP envelope. Crucible and Forge-Master tools route through the MCP handler (v2.82.1 fix).
POST	/api/tool/org-rules	Aliased convenience, forge_org_rules	Equivalent to POST /api/tool/forge_org_rules.
POST	/api/tool/run-plan	Aliased convenience, forge_run_plan	Equivalent to POST /api/tool/forge_run_plan; also surfaced as /api/runs/trigger with a friendlier shape.

Forge-Master (conversational entrypoint)

The HTTP surface for the conversational classifier described in the Forge-Master chapter. Lives alongside the main API on the same port; chat sessions are persistent and resumable.

Method	Path	Purpose	Notes
GET	/api/forge-master/capabilities	Classifier + tool surface metadata	What Forge-Master can do.
GET	/api/forge-master/prompts	Suggested starter prompts	Surfaced by the dashboard chat panel.
GET	/api/forge-master/sessions	List active chat sessions	Returns { sessions: [{ id, summary, lastTurnAt }] }.
GET	/api/forge-master/session/:id	Fetch one session	Full turn history.
POST	/api/forge-master/chat	Start a chat or send a turn	Body: { sessionId? message }. Returns { sessionId, response }.
GET	/api/forge-master/chat/:sessionId/stream	Server-Sent Events stream of a turn	For incremental rendering.
POST	/api/forge-master/chat/:sessionId/approve	Approve a Forge-Master tool call	For tools requiring human approval (e.g. write actions).
GET	/api/forge-master/prefs	Read user preferences	Tone, verbosity, classifier mode.
PUT	/api/forge-master/prefs	Update preferences	Body: partial prefs.
GET	/api/forge-master/cache-stats	Embedding cache liveliness	Hit rate, useful as a Forge-Master health probe.

Image generation

The single image-generation endpoint. Routes to xAI Grok Aurora (if XAI_API_KEY is set) or OpenAI DALL-E (if OPENAI_API_KEY is set). Auto-detects the available provider.

Method	Path	Purpose	Notes
POST	/api/image/generate	Generate an image	Body: { prompt, size? count? provider? }. Returns { images: [{ url, b64? }] }.

Worked examples

Five short recipes that cover the most common external-integration patterns. All examples assume the server is running at http://127.0.0.1:3100.

1. Trigger a plan run from a shell script

curl -X POST http://127.0.0.1:3100/api/runs/trigger \
  -H 'Content-Type: application/json' \
  -d '{
        "plan":   "docs/plans/Phase-28-PLAN.md",
        "mode":   "auto",
        "quorum": "auto"
      }'

# Returns: { "runIdx": 47, "pid": 18432 }

2. Stream live events with wscat

wscat -c ws://127.0.0.1:3100/api/hub

> {"type":"hello"}
< {"version":1,"type":"connected","timestamp":"2025-06-15T12:34:56.789Z","source":"hub"}
< {"version":1,"type":"slice-started","timestamp":"...","source":"orchestrator", ...}

Full event catalog in Appendix V.

3. Search across memory, plans, and bugs

curl 'http://127.0.0.1:3100/api/search?query=anvil+cache&source=memory&limit=10'

# Returns the gold-standard ACI shape:
# {
#   "hits":      [ { source, recordRef, snippet, score, timestamp } ],
#   "total":     27,
#   "truncated": true,
#   "message":   "Showing 10 of 27 hits across source=memory."
# }

4. Invoke any MCP tool generically

curl -X POST http://127.0.0.1:3100/api/tool/forge_estimate_quorum \
  -H 'Content-Type: application/json' \
  -d '{ "plan": "docs/plans/Phase-28-PLAN.md" }'

# Returns the tool's output payload unwrapped from the MCP envelope:
# { "modes": { "auto": {...}, "power": {...}, "speed": {...}, "false": {...} } }

5. Approve a bridge-paused run from a browser link

# VS Code notification or email link contains:
# https://127.0.0.1:3100/api/bridge/approve/47?token=<HMAC>
#
# Clicking opens a confirm page that POSTs back with the decision.
# Programmatic equivalent:

curl -X POST http://127.0.0.1:3100/api/bridge/approve/47 \
  -H 'Content-Type: application/json' \
  -H 'X-Bridge-Token: <HMAC>' \
  -d '{ "decision": "approve", "note": "Looks good, ship it" }'

Using the SDK instead

The pforge-sdk wraps the REST API with typed helpers. Prefer it when integrating from JavaScript/TypeScript:

import { client } from 'pforge-sdk';

const c = client({ baseUrl: 'http://127.0.0.1:3100' });

const runs     = await c.get('/api/runs/latest');
const estimate = await c.callTool('forge_estimate_quorum', {
  plan: 'docs/plans/Phase-28-PLAN.md',
});

See also

• Appendix V — Event Catalog, every event emitted over /api/hub
• Appendix Q — API Surface Index, the MCP tool surface that the dispatcher delegates to
• Appendix T — .forge.json Reference, configuration keys that several endpoints read or write
• Appendix U — Environment Variables Reference, PLAN_FORGE_HTTP_PORT, PFORGE_BRIDGE_SECRET, provider keys
• Chapter 29 — Integrating from Outside, end-to-end integration patterns
• Chapter — Dashboard, the primary REST consumer, browsable at http://127.0.0.1:3100/dashboard
• docs/REST-API.md on GitHub, auto-generated endpoint dump (regenerated via node scripts/dump-rest-routes.mjs)
